1500W/2000W/3000W 4-in-1 Handheld Fiber Laser Welder

The WORLDRAY 4-in-1 Handheld Fiber Laser Welder integrates welding, cutting, cleaning, and seam processing in one industrial-grade system. With 1500W/2000W/3000W power options, 0.5–6mm material compatibility, 7-inch multilingual touchscreen, red light positioning, and dual-temperature water cooling, it delivers precision, efficiency, and reliability across metal fabrication, automotive, appliance, construction, and hardware industries.

Model: DR-HL3000W

✔4-in-1 Function

✔Smart Control

✔Industrial Stability

Intelligent control

High-Speed

High-Precision

PRODUCT DETAILS

4-in-1 Multi-function Integration

One device integrates welding, cutting, cleaning, and seam processing, saving equipment cost and space.

Wide Material Compatibility

Supports 0.5-6mm metal thickness, covering thin to medium-thick plates for most industrial applications.

High-speed Welding Capability

Welding speed adjustable from 0-120mm/s, significantly improving production efficiency.

Red Light Precision Positioning

Built-in red light guidance for real-time focusing, improving welding accuracy and consistency.

Industrial-grade Safety Certification

CE certified, meeting international safety standards for operator and equipment protection.

Intelligent Touchscreen Interface

7-inch multilingual touchscreen with preset material parameters for one-click access, reducing learning curve.

Flexible Fiber Length Options

Standard 10m fiber, customizable up to 15m, suitable for long-distance and complex spatial operations.

High Power Stability

98% power stability with dual temperature-controlled water cooling ensures uninterrupted long-term operation.

Modular Structural Design

Modular core components for easy assembly, maintenance, and replacement, reducing downtime.

Comprehensive After-sales Support

12-month warranty, lifetime technical support, and 24-hour response

Parameter of Equipments

Parameter	Specification
Machine model	DR-HL3000W
Laser power supply	1500W / 2000W / 3000W (Optional)
Cooling-down method	Water Cooling
Laser wavelength	1080nm
Welding Thickness	0.5-6mm
Welding Speed	0-120mm/s
Fiber Length	10m (Standard), 15m (Optional)
Wire Feeding	With Wire Feeder
Applicable Materials	Stainless Steel, Aluminum, Iron, Copper, Zinc
Dimensions	1115mm × 525mm × 1000mm
Weight	78.5KG
Certification	CE Certified
